- Size: 11
- Place of Origin: Automatic door packing machine is good for the protection packaging of any doors, windows and profiles. It is mainly composed o
- Brand Name: jinglin
- Model Number: JL
- Weight: 10000.000 kg
Automatic door packing machine is good for the protection packaging of any doors, windows and profiles. It is mainly composed of the sealing part and the shrinking part. Carbon steel is used as its framework material. The sealing part is operated under the PLC control that is able to carry through full packaging.
Parameters of the Parts of Automatic Door Packing Machine
Sealing Part
Control: PLC
Structure material: carbon steel
Packing objects: length: 1000-3000mm; width: 600-900mm; height: 30-150mm
Height of working table: approx. 800mm
Conveyor speed: approx. 4-9m/min
Packaging type: full packaging
Packing material: PE /POF /PVC film with reserve pore.
Sealing part power consumption: approx. 4KW
Power supply: 380V
Air supply: 6~8 kgf/cm2
Shrinking Part
Structure material: carbon steel
Length: 4000mm
Shrinking tunnel: 3000mm
Shrinking side: W 1200mm x H 300mm
Heating power consumption: approx. 18Kw
Calorific: 4PCS
Cooling fans: 1 Group
Drive part: frequency control motor
Conveyor speed: approx. 3-8m/min
Temperature: 100℃-220℃
Packing material: PE /POF film with reserve pore.
Power supply: 380V
