Type: Wrapping Machine, Packing Machine
Condition: New
Application: Commodity, Machinery & Hardware
Packaging Type: Barrel
Packaging Material: Plastic, Paper, Other
Automatic Grade: Automatic
Driven Type: Electric
Place of Origin: Shanghai, China (Mainland)
Brand Name: JL
Model Number: GG Series
Certification: CE, ISO9001
Packaging & Delivery
Packaging Details: export standard fumigation-free wooden case Delivery Detail: 30-50 days depending on the machine
Steel bar wrapping machine
PLC control adopted
Good quality and reasonable price
OEM are welcomed
APPLICATION:
GG series Steel bar wrapping machine for horizontal was designed mainly for metallurgical industries. The machine could be widely used in the exterior wrapping of horizontal shapes such as steel bar/pipe/tube, stainless steel tube,aluminum tube,rubber tube, shapes like bar floor board & etc.
FEATURES:
PLC & HMI are adopted.
Double-ring & double-rub wheel devices make working more safe stable & energetic.
Special conveying device is easy for loading & conveying the package strengthens the transfer capacity.
Wide packing belt can be used for cutting the packing cost & making the work more efficiency.
Indicator alarms automatically when trouble occurs. Trouble can be shown.
Photocell sensor is adopted for setting packing position.
The turning ring is controlled by converter. Overlap rate could be adjusted according to the requirement.
Height of the ring centre could be adjusted.
Separate control panel makes operation & maintenance easily.
Material tension could be adjusted automatically.
TECHNICAI DATA:
ITEMS | GG500 | GG800 | GG1000 | GG1600 |
Package width | 100-500mm | 100-800mm | 100-1000mm | 100-1600mm |
Package length | Not limited | Not limited | Not limited | Not limited |
Conveyer length | 9000mm*2 Or on request | 9000mm*2 Or on request | 9000mm*2 Or on request | 9000mm*2 Or on request |
Conveying speed | About 8m/min | About 7m/min | About 6m/min | About 4m/min |
Rotating speed | About 60r/min | About 50r/min | About 45r/min | About 30r/min |
Conveyer height | 800mm | 1000mm | 1000mm | 1200mm |
Max loading | 2000kg | 3000kg | 4000kg | 5000kg |
Overlap scope | About 30%-70% | About 30%-70% | About 30%-70% | About 30%-70% |
Power output | About 7kw | About 9kw | About 12kw | About 16kw |
Power voltage | 380V/3phase/50Hz | 380V/3phase/ 50Hz | 380V/ 3phase/50Hz | 380V/3phase/50Hz |
Material | Compound paper tape/knit tape/anti-rust tape/waterproof tape/ stretch film/flax | Compound paper tape/knit tape/anti-rust tape/waterproof tape/ stretch film/flax | Compound paper tape/knit tape/anti-rust tape/waterproof tape/ stretch film/flax | Compound paper tape/knit tape/anti-rust tape/waterproof tape/ stretch film/flax |
Material size | width:≤250mm Max OD:400mm ID:55mm | width:≤250mm Max OD:400mm ID:55mm | width:≤250mm Max OD:400mm ID:55mm |
