Type: Wrapping Machine, Wrapping Machine, General
Condition: Used
Year: in 1988 year
Power: 4.5kw
Place of Origin: Shanghai, China (Mainland)
Brand Name: JINGLIN
Model Number: JL2100-W
Driven Type: eletric
Packaging Material: Plastic
Usage: Outer
Packaging Type: by cartons
Automatic Grade: Automatic
Packaging & Delivery
Packaging Details: soft packing or in standard wooden case Delivery Detail: 35 Days
TECHNICAI DATA:
ITEMS | DATA |
Working mode | Fully automatic |
Turntable motor power | 1.5kw |
Up-down motor power | 0.75kw |
Front conveying power | 0.75kw |
Back conveying power | 0.75kw |
Turntable speed | 13r/min |
Film carriage speed | 3m/min |
Roller speed | 8m/min |
Conveying speed | 8m/min |
Turntable diameter | 2300mm |
Packing speed | About 2030pallet/hour |
Overall dimensions | L3400mm W2300mm H3500mm (not include the front lineback line and guardrail) |
Machine weight | 2000kg(not include the front lineback line and guardrail) |
Turntable height | 500mm |
Max turntable loading | 2500kg |
Max packing size | L1600mm W1200mm H2500mm |
Power voltage | AC/220V/50Hz |
Air pressure | 6-8kgf/cm2 |
