Type: Wrapping Machine, General
Condition: New
Packaging Type: bundles
Packaging Material: Plastic, Paper
Automatic Grade: Automatic
Driven Type: Electric
Power: 9KW
Place of Origin: Shanghai, China (Mainland)
Brand Name: JINGLIN
Model Number: GG800
Certification: CE,ISO9001
Usage: Outer
Character: Horizontal wrapping
Packaging & Delivery
Packaging Details: Export standard fumigation-free wooden case Delivery Detail: according to requirement
pipe bundle packing machine
high quality,good performance
reliable technical support and service.
Pipe bundle packing machine
APPLICATION:
Mainly designed for metallurgical industries.It can widely be used in the exterior wrapping of horizontal shapesobjects such as steel tube/pipe, stainless steel tube,aluminum tube, rubber tube, doors,floor board & etc.
FEATURES:
*PLC&HMI are adopted.
*Double-ring&double-rub wheel devices make working more safe,stable and energetic;
*Special conveying device is easy for loading&conveying the package strengthens the transfer capacity;
*Wide packing belt can be used for cutting the packing cost&making the work more efficiency;
*Indicator alarms automatically when trouble occurs.Trouble can be shown.
*Photocell sensor is adopted for setting packing position;
*The turning ring is controlled by converter. Overlap rate could be adjusted according to the requirement;
*Separate control panel makes operation&maintenance easily;
*Height of the ring centre could be adjusted;
*Material tension could be adjusted automatically.
TECHNICAI DATA:
Items | GG500 | GG800 | GG1000 | GG1600 |
Package width | 100-500mm | 100-800mm | 100-1000mm | 100-1600mm |
Package length | Not limited | Not limited | Not limited | Not limited |
Conveyer length | 9000mm*2 Or on request | 9000mm*2 Or on request | 9000mm*2 Or on request | 9000mm*2 Or on request |
Conveying speed | About 8m/min | About 7m/min | About 6m/min | About 4m/min |
Rotating speed | About 60r/min | About 50r/min | About 45r/min | About 30r/min |
Conveyer height | 800mm | 1000mm | 1000mm | 1200mm |
Max loading | 2000kg | 3000kg | 4000kg | 5000kg |
Overlap scope | About 30%-70% | About 30%-70% | About 30%-70% | About 30%-70% |
Power output | About 7kw | About 9kw | About 12kw | About 16kw |
Power voltage | 380V/50Hz | 380V/ 50Hz | 380V/ 50Hz | 380V/50Hz |
Material | Compound paper tape/knit tape/anti-rust tape/waterproof tape/ stretch film/flax | Compound paper tape/knit tape/anti-rust tape/waterproof tape/ stretch film/flax | Compound paper tape/knit tape/anti-rust tape/waterproof tape/ stretch film/flax | Compound paper tape/knit tape/anti-rust tape/waterproof tape/ stretch film/flax |
Material size | width:≤250mm Max OD:400mm ID:55mm | width:≤250mm Max OD:400mm ID:55mm | width:≤250mm Max OD:400mm ID:55mm | width:≤250mm Max OD:400mm ID:55mm |
